On the bench · BWP-P-005

Downdraftsanding tables

Five downdraft plan sets from one design family, from a quiet 120 V table for finish-sanding MDF doors to a 240 V production table. You cut the parts on your own router.

Coming soon · not on sale yet The plans are drawn. The table isn't built yet. Email me at launch →

Side by side

Compare the five models

Downdraft Model Guide comparison chart: Lite, LitePlus, Compact, Standard and Pro 240 V side by side, with each model's drawing, who it is for, top size, power, airflow, build cost, strengths and trade-offs

Swipe the chart sideways →

From the Downdraft Model Guide, Sept 2026. Airflow is calculated in the plans, not measured on a finished table yet. Build cost is the guide's estimate to build the table yourself, not the price of the plans. Specs may change before launch.

Downdraft Model Guide comparison chart, full size

Model by model

Look at each table

Building MDF doors? Start with the Lite, or the LitePlus if you sand all day. The cyclone tables are for shops that also make heavy, coarse dust.

Drawing of the Lite downdraft table (DDT-7236L) from the Downdraft Model Guide
Best for MDF doors

Lite

Cabinet shops finish-sanding MDF doors and panels (120–320 grit, primer scuffing).

  • Top72″ × 36″, 32 cells
  • Power120 V, 9 A blower (20 A circuit)
  • Whole top96–105 fpm
  • Best zone135–147 fpm over 36″ × 36″
  • Footprint72″ × 36″ × 36″ H
  • Plan set29 pages + CNC

Strengths

  • The whole 72″ × 36″ top at about 100 fpm, even with four doors on risers.
  • Lowest cost: one 120 V circuit and a quiet furnace blower.
  • Smallest footprint: no tower, ducting or drum.

Trade-offs

  • No cyclone: the filters take all the dust; airflow drops about 8% before service.
  • Prefilters are a running cost, more so with primer.
  • Not for coarse grits or heavy stock removal.
Drawing of the LitePlus downdraft table (DDT-7236LP) from the Downdraft Model Guide
Door production

LitePlus

Door shops finish-sanding MDF every day that want the filters to stay put and the finest dust caught.

  • Top72″ × 36″, 32 cells
  • Power240 V, 3 HP + shop air
  • Whole top94–104 fpm (118–121 Chicago)
  • Best zone176–194 fpm over 36″ × 36″
  • Footprint98″ × 36″, 56″ tower
  • Plan set33 pages + CNC

Strengths

  • Whole top at about 100 fpm, and about 120 with the Chicago blower.
  • Press CLEAN at the end of the day: the cartridges stay in and last years.
  • MERV 15 nanofiber media, plus a dust drawer instead of dusty filter changes.

Trade-offs

  • Costs three to four times as much as the Lite to build.
  • Needs 240 V and shop air that holds 90 psi.
  • 98″ long with a 56″ tower, and about 630 lb.
Drawing of the Compact downdraft table (DDT-5436) from the Downdraft Model Guide
Small shops

Compact

Smaller shops sanding solid-wood parts through coarse and fine grits, often with a 120 V collector already on hand.

  • Top54″ × 36″, 24 cells
  • Power120 V, 12–16 A collector
  • Whole top45–49 fpm
  • Best zone122–131 fpm over 18″ × 36″
  • Footprint88″ × 36″, 55″ tower
  • Plan set30 pages + CNC

Strengths

  • Cyclone drops chips and coarse dust into a drum, so airflow stays steady between filter services.
  • A 54″ top and 88″ overall length fit tighter shops.
  • Runs on a common 120 V collector, or one you already own.

Trade-offs

  • Only an 18″ × 36″ zone reaches 100+ fpm; the whole top gets under 50 fpm.
  • The 55″ cyclone tower adds height and length.
  • Costs more to build than the Lite and moves about a third of the air.
Drawing of the Standard downdraft table (DDT-7236) from the Downdraft Model Guide
Mixed work

Standard

General woodshops with mixed work: solid wood, coarse grits and long parts, on 120 V.

  • Top72″ × 36″, 32 cells
  • Power120 V, 12–16 A collector
  • Whole top34–37 fpm
  • Best zone122–131 fpm over 18″ × 36″
  • Footprint106″ × 36″, 55″ tower
  • Plan set30 pages + CNC

Strengths

  • A 72″ top with column zoning handles long parts.
  • Cyclone and drum take the heavy dust; the filters last.
  • Reuses a 120 V collector you already own, which cuts the cost a lot.

Trade-offs

  • Only an 18″ × 36″ zone reaches 100+ fpm; the whole top gets 34–37 fpm.
  • Needs blanking mats for most jobs.
  • 106″ long with the tower, and about 590 lb.
Drawing of the Pro 240 V downdraft table (DDT-7236P) from the Downdraft Model Guide
Production

Pro 240 V

Production shops with 240 V doing heavy stock removal and large panels all day.

  • Top72″ × 36″, 32 cells
  • Power240 V, 3 HP blower
  • Whole top56–67 fpm
  • Best zone107–127 fpm over 36″ × 36″
  • Footprint107″ × 36″, 70″ tower
  • Plan set30 pages + CNC

Strengths

  • A 36″ × 36″ zone at 107–127 fpm, and 136–161 fpm over 27″ × 36″.
  • The XL cyclone handles heavy dust loads for hours.
  • Built for production duty, with headroom for a 5 HP blower.

Trade-offs

  • Needs a 240 V circuit, and costs more than the 120 V tables.
  • 70″ tower, 107″ long, about 690 lb.
  • The whole top still gets only 56–67 fpm.
Finish-sanding MDF doors all day, with 240 V and shop airLitePlus
Mostly finish-sanding MDF doors and panelsLite
Heavy stock removal or production, and 240 VPro 240 V
Parts under 54″, or short on floor spaceCompact
Everything else on 120 VStandard

Drawings are from the Downdraft Model Guide. Shop photos come after the first table is built.

Look inside

Plan preview

Three pages from the LitePlus plan set. Every number is blacked out. The full set has the dimensions, cut list and sheet layouts.

LitePlus plan set cover page, numbers removed, with a drawing of the 3-D model
CoverModel drawing, not a photo
Plan page 'How the air moves': a section through the table showing the airflow path, numbers removed
How the air movesNumbers removed
Plan page 'General arrangement': front and end elevations, dimensions removed
General arrangementDimensions removed

Every plan set includes:

  • The airflow math
  • A full cut list and sheet layouts
  • Drawings and a build sequence
  • CNC files
